Aspire in a Sandbox

This is a follow-up to Sandboxing the Eager Deputy, which makes the case for running AI agent code inside an isolation boundary rather than trusting the agent to behave. This post is the hands-on companion: a complete, modern .NET Aspire dev environment running inside a Gondolin micro-VM, with containers, network mediation, and host-accessible services.

What we’re building

#

An Aspire AppHost that orchestrates an nginx container, with both the Aspire dashboard and nginx accessible from the host through Gondolin’s ingress gateway. The VM has no direct network access. NuGet packages and Docker images are pulled through Gondolin’s HTTPS-intercepting proxy, which enforces an explicit hostname allowlist. The project source is mounted into the VM via a programmable filesystem layer. The goal is to show that a sandboxed environment can handle a real development workflow without compromise.

Prerequisites

#

Gondolin runs on Linux, macOS, and WSL2. Native Windows host support is tracked in #21.

Everything in this post was done on Ubuntu 24.04 under WSL2 with QEMU. Gondolin also supports libkrun as an alternative VMM backend; I used QEMU because it required no additional setup. Adjust commands for your distribution.

sudo apt install qemu-system-x86_64 cpio lz4 nodejs npm

You’ll also need Zig 0.15.2 (for cross-compiling guest binaries when building custom images) and Docker or Podman on the host (for building images). .NET is only needed inside the VM, not on the host.

Enable KVM

#

Without KVM, QEMU falls back to software emulation and the difference is not subtle: dotnet restore took over 30 minutes in TCG mode and 30 seconds with KVM.

sudo usermod -aG kvm $USER
# Then from the host: wsl --shutdown, and reopen

Build from native paths

#

If you’re building custom Gondolin images from a Windows-mounted checkout, you’ll hit errors like AccessDenied when the Zig compiler tries to write to its cache under /mnt/c/.... Copy the source to a native ext4 path first (e.g., ~/gondolin).

Step 1: Build a VM image with .NET and Docker

#

Gondolin’s default Alpine image is minimal. We need .NET SDK 10 and Docker inside the VM, which means building a custom image. Alpine 3.23 packages both dotnet10-sdk and Docker in its community repository, so everything installs at build time with no extra steps.

Create build-config.json:

{
  "arch": "x86_64",
  "distro": "alpine",
  "alpine": {
    "version": "3.23.0",
    "kernelPackage": "linux-virt",
    "kernelImage": "vmlinuz-virt",
    "rootfsPackages": [
      "linux-virt", "rng-tools", "bash", "ca-certificates", "curl",
      "openssh", "git", "dotnet10-sdk",
      "docker", "docker-cli", "containerd", "runc", "iptables"
    ],
    "initramfsPackages": []
  },
  "rootfs": {
    "label": "gondolin-root",
    "sizeMb": 4096
  },
  "init": {
    "rootfsInitExtra": "docker-init-extra.sh"
  }
}

The 4GB rootfs gives Docker room for pulled container images. Gondolin also supports OCI base images (e.g., mcr.microsoft.com/dotnet/sdk:10.0-alpine) depending on your use case.

The Docker init script

#

The rootfsInitExtra field points to docker-init-extra.sh, a shell script that runs at VM boot:

# Set up cgroup v2 for Docker container support
mkdir -p /sys/fs/cgroup 2>/dev/null || true
if ! grep -q " /sys/fs/cgroup " /proc/mounts; then
  mount -t cgroup2 cgroup2 /sys/fs/cgroup 2>/dev/null || true
fi

# Create runtime directories Docker expects
mkdir -p /var/run /var/lib/docker /run/docker
export PATH=/usr/local/bin:$PATH

# Enable IPv4 forwarding for Docker bridge networking
sysctl -w net.ipv4.ip_forward=1 >/dev/null 2>&1 || true

# Start dockerd with the VFS storage driver (overlayfs is
# not available in the minimal VM kernel)
if command -v dockerd > /dev/null 2>&1; then
  dockerd \
    --host=unix:///var/run/docker.sock \
    --exec-root=/run/docker \
    --data-root=/var/lib/docker \
    --storage-driver=vfs \
    --iptables=true \
    --ip-forward=true \
    --ip-masq=true \
    > /var/log/dockerd.log 2>&1 &
fi

# Poll until dockerd is ready (up to 6 seconds)
if command -v docker > /dev/null 2>&1; then
  i=0
  while [ $i -lt 60 ]; do
    if docker info > /dev/null 2>&1; then break; fi
    sleep 0.1
    i=$((i + 1))
  done
fi

This script runs under busybox ash, not bash, so stick to POSIX constructs. Every command must be safe to fail (|| true or 2>/dev/null); a non-zero exit kills PID 1 and kernel-panics the VM. And the file must have Unix line endings (LF); CRLF will cause a kernel panic.

Build and verify

#

gondolin build --config build-config.json --output ./assets

gondolin exec --image <build-id> -- dotnet --version
# 10.0.105

gondolin exec --image <build-id> -- docker version
# Docker Engine + Client

Step 2: Create the Aspire AppHost

#

Using .NET 10’s single-file app format:

// apphost.cs
#:sdk Aspire.AppHost.Sdk@13.0.2

var builder = DistributedApplication.CreateBuilder(args);
builder.AddContainer("nginx", "nginx").WithHttpEndpoint(targetPort: 80);
builder.Build().Run();

One configuration change: the http launch profile binds to localhost by default, but Gondolin’s ingress gateway connects to guest 127.0.0.1. On some configurations localhost resolves to IPv6 ::1, which the ingress can’t reach. Edit Properties/launchSettings.json:

- "applicationUrl": "http://localhost:15194"
+ "applicationUrl": "http://0.0.0.0:15194"

Step 3: Configure the VM

#

import { VM, RealFSProvider, createHttpHooks } from "@earendil-works/gondolin";

const { httpHooks, env } = createHttpHooks({
  allowedHosts: [
    "*.nuget.org",                  // NuGet
    "*.docker.io",                  // Docker Hub auth + registry
    "*.cloudflare.docker.com",      // Docker Hub blob redirects
    "*.r2.cloudflarestorage.com",   // Docker Hub blob storage
    "*.microsoft.com",              // MCR, telemetry, SDK downloads
    "dotnetcli.azureedge.net",      // .NET SDK
  ],
});

const vm = await VM.create({
  httpHooks, env,
  memory: "4G",  // Default 1GB causes OOM during dotnet restore
  cpus: 4,
  sandbox: { imagePath: "./assets" },
  vfs: {
    mounts: {
      "/workspace": new RealFSProvider("./"),
      // Mount a host directory as the NuGet cache so packages persist
      // across VM instances instead of re-downloading every boot.
      "/root/.nuget/packages": new RealFSProvider("./.nuget-cache"),
    },
  },
});

Docker Hub’s pull flow redirects blob downloads to blob storage under hostnames like docker-images-prod.*.r2.cloudflarestorage.com. Use GONDOLIN_DEBUG=net to see exactly which hostnames are needed for your scenario.

HTTPS interception

#

All HTTPS traffic from the VM goes through Gondolin’s MITM proxy. The host generates a local CA certificate and makes it available inside the guest at /etc/gondolin/mitm/ca.crt. The guest init scripts build a merged trust bundle so standard tools (curl, dotnet, docker) trust the proxy automatically. Docker containers that need to make outbound HTTPS calls will need the CA bundle mounted in; Gondolin’s upstream docker example handles this with a wrapper script.

Step 4: Restore, build, run

#

// Restore and build
await vm.exec("cd /workspace && dotnet restore");
await vm.exec("cd /workspace && dotnet build --no-restore");

// Start Aspire
const proc = vm.exec(
  "cd /workspace && " +
  "ASPIRE_ALLOW_UNSECURED_TRANSPORT=true " +
  "DOTNET_DASHBOARD_UNSECURED_ALLOW_ANONYMOUS=true " +
  "dotnet run --launch-profile http --no-build",
  { stdout: "pipe", stderr: "pipe" },
);

// Wait for Kestrel to start accepting connections
for await (const chunk of proc.output()) {
  if (chunk.text.includes("Now listening")) break;
}

Step 5: Expose via ingress

#

Gondolin’s ingress gateway maps host HTTP requests to guest services using prefix-based routing. A request to /nginx/foo on the host gets forwarded to the nginx port inside the VM as /foo (with the /nginx prefix stripped). When multiple routes are defined, the longest matching prefix wins, so /nginx takes priority over / for requests starting with /nginx.

const ingress = await vm.enableIngress({
  listenHost: "127.0.0.1",
  listenPort: 0,
});

// Route the Aspire dashboard
vm.setIngressRoutes([
  { prefix: "/", port: 15194, stripPrefix: false },
]);
console.log("Dashboard:", ingress.url);

Aspire assigns a dynamic port to the nginx container via DCP. Once the container is running, query its port and add an ingress route:

const ports = await vm.exec("docker ps --format '{{.Ports}}'");
const portMatch = ports.stdout.match(/:(\d+)->80/);
if (portMatch) {
  const nginxPort = parseInt(portMatch[1]);
  vm.setIngressRoutes([
    { prefix: "/nginx", port: nginxPort, stripPrefix: true },
    { prefix: "/", port: 15194, stripPrefix: false },
  ]);
  console.log("nginx:", new URL("/nginx/", ingress.url).href);
}

What the sandbox actually does

#

From inside the VM, try reaching a host you haven’t allowlisted:

const blocked = await vm.exec(
  "curl -s -o /dev/null -w '%{http_code}' https://evil.example.com"
);
// "000" - connection refused. The host never existed inside the VM's network.

const allowed = await vm.exec(
  "curl -s -o /dev/null -w '%{http_code}' https://api.nuget.org/v3/index.json"
);
// "200" - allowlisted, passes through the proxy.

The agent can restore packages, pull containers, and serve HTTP. It cannot exfiltrate data to an unapproved destination. And the credentials it uses for approved destinations are injected at the proxy layer; they never exist inside the VM.

Loosening the reins

#

The strict allowlist in this walkthrough is appropriate for running untrusted agent-generated code. But for day-to-day development, you need Stack Overflow, package registries, documentation sites. A locked-down allowlist would make that miserable, and security tooling that makes developers miserable doesn’t get used. It gets disabled. Then you’ve lost both the allowlist and the credential isolation.

Gondolin separates network access from credential access. These are independent controls. Set allowedHosts: ["*"] and the agent can reach any host, but secrets still only get injected for the specific destinations you’ve approved:

const { httpHooks, env } = createHttpHooks({
  allowedHosts: ["*"],
  secrets: {
    GITHUB_TOKEN: {
      hosts: ["api.github.com"],
      value: process.env.GITHUB_TOKEN,
    },
  },
});

The network is open. The credentials are not. Inside the VM, $GITHUB_TOKEN contains a placeholder like GONDOLIN_SECRET_4eeaf8de.... When the agent sends a request to api.github.com with that placeholder in the Authorization header, the proxy substitutes the real token. When the agent sends the same placeholder to any other host, the placeholder goes through as-is. The real token never enters the VM.

The allowlist is defense in depth. Secret injection is the core guarantee. You can relax one without compromising the other.

Wiring it to an agent

#

For Copilot CLI, the extension system provides lifecycle hooks and tool interception. An extension can boot the VM on session start and rewrite shell commands to execute inside it:

// Conceptual sketch - not production code
import { execFile, execFileSync } from "node:child_process";
import { joinSession } from "@github/copilot-sdk/extension";

const isWindows = process.platform === "win32";

// Wrap gondolin CLI calls so they work on both platforms.
// On Windows, commands run inside WSL where Gondolin is installed.
// Once native Windows support lands (#21), this wrapper goes away
// and we can use the gondolin sdk directly.
function gondolin(...args) {
  if (isWindows) return execFileSync("wsl", ["-e", "gondolin", ...args], { encoding: "utf-8" });
  return execFileSync("gondolin", args, { encoding: "utf-8" });
}

let vmProcess;
let sessionSock;

const session = await joinSession({
  hooks: {
    onSessionStart: async () => {
      // Boot a persistent VM with the project mounted at /workspace.
      const vmArgs = [
        "bash",
        "--image", "./assets",
        "--mount-hostfs", `${process.cwd()}:/workspace`,
        "--allow-host", "*",
      ];

      vmProcess = isWindows
        ? execFile("wsl", ["-e", "gondolin", ...vmArgs])
        : execFile("gondolin", vmArgs);

      // Wait for the session to register, then find its socket.
      await new Promise(r => setTimeout(r, 5000));
      const list = gondolin("list");
      const match = list.match(/^(\S+)/m);
      sessionSock = `~/.cache/gondolin/sessions/${match[1]}.sock`;
    },

    onPreToolUse: async (input) => {
      if (input.toolName === "powershell" || input.toolName === "bash") {
        // Rewrite the command to execute inside the running VM.
        const execCmd = isWindows
          ? `wsl -e gondolin exec --sock ${sessionSock} -- ${input.toolArgs.command}`
          : `gondolin exec --sock ${sessionSock} -- ${input.toolArgs.command}`;
        return { modifiedArgs: { ...input.toolArgs, command: execCmd } };
      }
    },

    onSessionEnd: async () => {
      vmProcess?.kill();
    },
  },
});

The agent doesn’t know it’s sandboxed. It calls the same tools it always calls. The extension rewrites the command so powershell executes it inside the VM instead of on the host. This is the same pattern pi-gondolin uses for the Pi coding agent.

The full integration, including interactive sessions, file synchronization, and port forwarding, is a topic for a dedicated post.

Rough edges

#

The init script is the hardest part to get right. Errors manifest as “the VM didn’t boot” with no useful feedback. The only debugging tool is GONDOLIN_DEBUG=protocol and reading the kernel console output for clues. Once it works, it works reliably, but the first iteration takes patience.

There’s meaningful setup cost before you can use this day-to-day. Building a custom image, configuring allowlists, writing the init script, wiring up the agent extension. This is infrastructure work, and it’s front-loaded.
